Capillary TYPE Thermometer Gas Filled In India
- Eco-Friendly Inert Nitrogen Gas (Class IIIB) Expansion System (100% Mercury-Free)
- Flexible Stainless Steel Armored Capillary Tube Available up to 20 Meters
- Wide Temperature Ranges from -50°C to +600°C with Fast Response Time
- Panel Clamp, Wall Surface Flange, or Back Flange Mounting Configurations
FGB Precision Assembly: Capillary TYPE Thermometer Gas Filled In India
Standard Technical Specifications
Engineered to satisfy demanding industrial criteria. Review our standard parameter ranges or request custom connection threads, dial branding, and special wetted alloys.
| Specification Parameter | Standard Technical Values / Manufacturing Options |
|---|---|
| Dial Sizes | 100mm (4"), 150mm (6"), 250mm (10") |
| Operating Principle | Gas Expansion (Class IIIB, Non-Toxic Inert Nitrogen Gas) |
| Temperature Spans | -50°C to +50°C, 0-100°C, 0-150°C, 0-250°C, 0-400°C, 0-600°C |
| Accuracy Class | Class 1.0 (±1.0% FSD) conforming to EN 13190 / IS Standards |
| Capillary Line | AISI SS 304 / SS 316 capillary protected by flexible armored conduit (length: 1m to 20m) |
| Bulb Dimensions | Diameter 8mm, 10mm, 12mm; Length from 100mm up to 500mm in SS 316 |
| Process Connection | 1/2" BSP / NPT Adjustable Compression Sliding Gland |
| Ambient Compensation | Full bimetallic ambient temperature compensation inside case |
Key Engineering & Operational Advantages
Built for continuous 24/7 industrial performance, long service life, and unmatched measurement stability.
Remote Distance Monitoring
Mounts gauge at eye level in control rooms away from scorching ovens, vibrating tanks, or hazardous vessels.
100% Non-Toxic & Mercury Free
Safe for food processing, breweries, pharmaceuticals, and marine installations.
Flexible Armored Sheathing
Spiral stainless steel armor protects the delicate internal micro-bore tube from crushing and physical damage.
Adjustable Sliding Glands
Allows operators to adjust bulb insertion depth into thermowells without recalibrating.
Recommended Industries & Operating Environments
Trusted by plant engineers, system integrators, and OEM equipment builders across diverse sectors.
Frequently Asked Questions (FAQs)
Find answers to common technical queries regarding specifications, selection, calibration, and delivery.
The sensing bulb, capillary, and internal Bourdon tube are charged under pressure with pure nitrogen gas. When heat is applied to the bulb, the gas expands proportionally to temperature, causing the Bourdon tube to uncoil and move the pointer across the dial.
FGB gas-filled thermometers feature built-in bimetallic ambient compensation inside the movement case that automatically cancels out temperature variations along the capillary run.
Yes, we supply capillary thermometers with magnetic snap-action high/low alarm contacts to trip heaters or sound horns when limits are crossed.
Get Instant Pricing for Capillary TYPE Thermometer Gas Filled In India
Fill in your required quantity and dial specifications. Our technical engineering team will respond within 2 hours with wholesale factory pricing.
